Series 656
Precision Universal Vise
Horizontal rotary:
range 360°, graduation 0.05°
Vertical incline: range 45°, graduation 0.05°
With vertical incline adjust knob
Parallelism and squareness between A, B, C and D: 5μm/100mm, parallelism between
D and E at 0°: 10μm/100mm Made of tool steel
Hardness HRC56-58
Specifications
| Part No | Status | Jaw Opening | Jaw Width |
|---|---|---|---|
| AC-656-080-01 | Order In | 0-80mm | 70mm |
Note: ETA for Order In products is between 8-12 weeks.
