Series TT
Digital Torque Meter
For torque wrench and torque screw driver calibration
For clockwise and anti-clockwise operation
Unit: N.m, N.cm, kgf.cm, lbf.cm, lbf.in
Peak, preset and real-time working mode
Power off automatically
High and low limit with judgement
Specifications
| Part No | Status | Specification |
|---|---|---|
| AC-TT05 | Order In | Range: 0.1-5N.m
Accuracy: ±1% Resolution: 0.0001N.m Size of square drive: 1/4"" Conventor: without Power: AC/DC adapter Weight: 3.1kg Included accessories Main unit: 1pc Sensor(cable length 1.5m): 1pc 1.2m sensor extension cable: 1pc AC/DC adaptor: 1pc |
| AC-TT1000 | Order In | Range: 100-1000N.m
Accuracy: ±1% Resolution: 0.1N.m Size of square drive: 1"" Conventor: 1"" to 3/4"", 3/4"" to 1/2"", 1/2"" to 3/8"" Power: AC/DC adapter Weight: 6.4kg Included accessories Main unit: 1pc Sensor(cable length 1.5m): 1pc 1.2m sensor extension cable: 1pc AC/DC adaptor: 1pc |
| AC-TT220 | Order In | Range: 22-220N.m
Accuracy: ±1% Resolution: 0.01N.m Size of square drive: 1/2"" Conventor: 1/2"" to 3/8"", 3/8"" to 1/4"" Power: AC/DC adapter Weight: 3.6kg Included accessories Main unit: 1pc Sensor(cable length 1.5m): 1pc 1.2m sensor extension cable: 1pc AC/DC adaptor: 1pc |
| AC-TT2200 | Order In | Range: 220-2200N.m
Accuracy: ±1% Resolution: 0.1N.m Size of square drive: 1"" Conventor: 1"" to 3/4"", 3/4"" to 1/2"" Power: AC/DC adapter Weight: 6.4kg Included accessories Main unit: 1pc Sensor(cable length 1.5m): 1pc 1.2m sensor extension cable: 1pc AC/DC adaptor: 1pc |
| AC-TT5 | Order In | Range: 0.5-10N.m
Accuracy: ±1% Resolution: 0.0001N.m Size of square drive: 1/4"" Conventor: without Power: AC/DC adapter Weight: 3.1kg Included accessories Main unit: 1pc Sensor(cable length 1.5m): 1pc 1.2m sensor extension cable: 1pc AC/DC adaptor: 1pc |
| AC-TT50 | Order In | Range: 5-50N.m
Accuracy: ±1% Resolution: 0.001N.m Size of square drive: 3/8"" Conventor: 3/8"" to 1/4"" Power: AC/DC adapter Weight: 3.4kg Included accessories Main unit: 1pc Sensor(cable length 1.5m): 1pc 1.2m sensor extension cable: 1pc AC/DC adaptor: 1pc |
| AC-TT550 | Order In | Range: 55-550N.m
Accuracy: ±1% Resolution: 0.01N.m Size of square drive: 3/4"" Conventor: 3/4"" to 1/2"", 1/2"" to 3/8"" Power: AC/DC adapter Weight: 4.9kg Included accessories Main unit: 1pc Sensor(cable length 1.5m): 1pc 1.2m sensor extension cable: 1pc AC/DC adaptor: 1pc |
Note: ETA for Order In products is between 8-12 weeks.
