Series TTM
Digital Bottle Cap Torque Meter
Test the open and tighten torque of bottle cap
Peak, preset and real-time working mode
Unit: N.m, N.cm, kgf.cm, lbf.cm, lbf.in
Memory: 1000
Power off automatically
With software, can show the torque graph
Specifications
| Part No | Status | Specification |
|---|---|---|
| AC-TTM10 | Order In | Range: 0.5-10N.m
Accuracy: ±0.5% Resolution: 0.001N.m Open size: Ø19.5-190mm Output: USB and RS232 Power: rechargeable battery Weight: 2.5kg Included accessories Main unit: 1pc Charger: 1pc Software with cable: 1pc Optional accessories Wireless printer: PR100 |
| AC-TTM2 | Order In | Range: 0.1-2N.m
Accuracy: ±0.5% Resolution: 0.0002N.m Open size: Ø19.5-190mm Output: USB and RS232 Power: rechargeable battery Weight: 2.5kg Included accessories Main unit: 1pc Charger: 1pc Software with cable: 1pc Optional accessories Wireless printer: PR100 |
| AC-TTM20 | Order In | Range: 1-20N.m
Accuracy: ±0.5% Resolution: 0.002N.m Open size: Ø19.5-190mm Output: USB and RS232 Power: rechargeable battery Weight: 2.5kg Included accessories Main unit: 1pc Charger: 1pc Software with cable: 1pc Optional accessories Wireless printer: PR100 |
| AC-TTM5 | Order In | Range: 0.25-5N.m
Accuracy: ±0.5% Resolution: 0.0005N.m Open size: Ø19.5-190mm Output: USB and RS232 Power: rechargeable battery Weight: 2.5kg Included accessories Main unit: 1pc Charger: 1pc Software with cable: 1pc Optional accessories Wireless printer: PR100 |
Note: ETA for Order In products is between 8-12 weeks.
