Series TTS
Digital Torque Meter
Adjustable open size for fixing
Peak, preset and real-time working mode
Unit: N.m, N.cm, kgf.cm, lbf.cm, lbf.in
Memory: 1000
Power off automatically
With software, can show the torque graph
Specifications
| Part No | Status | Specification |
|---|---|---|
| AC-TTS1 | Order In | Range: 0.05-1N.m
Open size: Ø10mm Resolution: 0.0001N.m Accuracy: ±0.3% Memory: 1000 Output: USB and RS232 Power: rechargeable battery Weight: 0.7kg Included accessories Main unit: 1pc Charger: 1pc Software with cable: 1pc Wrench: 1pc Optional accessories Wireless printer: PR100 |
| AC-TTS10 | Order In | Range: 0.5-10N.m
Open size: Ø13mm Resolution: 0.001N.m Accuracy: ±0.3% Memory: 1000 Output: USB and RS232 Power: rechargeable battery Weight: 0.7kg Included accessories Main unit: 1pc Charger: 1pc Software with cable: 1pc Wrench: 1pc Optional accessories Wireless printer: PR100 |
| AC-TTS5 | Order In | Range: 0.25-5N.m
Open size: Ø10mm Resolution: 0.0005N.m Accuracy: ±0.3% Memory: 1000 Output: USB and RS232 Power: rechargeable battery Weight: 0.7kg Included accessories Main unit: 1pc Charger: 1pc Software with cable: 1pc Wrench: 1pc Optional accessories Wireless printer: PR100 |
Note: ETA for Order In products is between 8-12 weeks.
